New Product by Jiangxi Liansheng - Spring Damping Isolator

A new kind of spring damping isolator has been developed by our R&D Dept. successfully. The vibration isolation effect is proved to be excellent after repeated tests and analysis.

The elastic element of the spring damping isolator is composed of steel spring  and damping material, which has the advantages of low inherent frequency and large damping ratio. It eliminates the phenomenon of amplitude amplification when the steel spring resonates. A large number of experimental data shows that the theoretical calculation matches up with test data. The spring damping isolator has a good vibration isolation performance for the mid-to-high frequencies.

1. Main features:

Tempered springs with residual stress removed;

Good anti-fatigue performance;

Compact structure, and easy installation;

Large damping, and outstanding vibration isolation effect;

Oil, water and temperature change resistant;

Long service life, and minimum maintenance required;

Wide working environment adaptability.

2. Applications :

Optical microscopes

Medical & biology fields

Light path experiments

Optical fabrication

Laser scanning & interference

Air compressor, pumps and other equipment with vibration isolation and noise control requirements

3. Technical data：

(Note: The technical data in the above table are for our existing products, and could be customized according to customer’s individual requirements.)
